Low Power Paging Repeater

SKU WPRP-1

$645.00

In stock

Save this product for later

Product Details

Brand: Visiplex

Description

The WPRP-1 is a device that extends the range of wireless paging signals to areas where the main paging transmitter signal is either too weak or cannot be received. It can handle multiple paging data formats and can receive and transmit on two different frequency bands.

As part of Visiplex’s product line of Paging Transmitters and Receivers, the WPRP-1 can be used to improve coverage in applications such as one-way or two-way voice messaging, data paging, time synchronization, and more.

The WPRP-1 Wireless Repeater comes with a built-in transmitter, radio receiver, magnetic mount antenna, repeater control logic, and a programming port for configuration.

UHF Frequency Band
Digital and Analog Paging Formats
100mW Power Output
Highly Sensitive Receiver
Narrow Band Operation

Weight	3 lbs
Dimensions	8 × 8 × 4 in
Product Dimensions	7.6" x 5.1" x 3.0" (W x H x D) Adaptor: 4" x 7.5" x 3" Adaptor Cable Length: 6 ft. Power Cable Length: 6 ft.
Product Weight	1.9 lbs. (3.3 lbs. with Internal Battery)
Power	12V DC / 5A (Using 100-240V AC)
Color	Light Gray
Operating Temperature	32° – 120°F
Output Power	100mW
Receiver Sensitivity	<110dBm
Selectivity	50dB
Input / Output Impedance	50 Ohm
Modulation	FM
Frequency Range	VHF (148 – 174 MHz), UHF (400 – 470 MHz)
Channel Spacing	12.5 KHz – Narrow Band
Stability	± 2.5 ppm
Data Format	Digital 512-2400 BPS Analog – 100Hz – 3.6KHz
Enclosure	Plastic
Limited Warranty	One-Year Parts and Labor
