Alphanumeric Pager
The VP-4 alphanumeric pager is a device that has four lines and is specifically designed to work as an emergency pager where long text messaging is required. The pager can also be set as two lines of large text to make it easier to read. It includes a disposable AAA alkaline battery, a safety lanyard, and a carrying case.
The VP-4 alphanumeric pager can support six activation codes or IDs. These can be used for individual activation or membership activation in up to five different groups. By creating groups, users can activate multiple devices with a single transmission from a main wireless paging controller like the VS4810 or VNS5100.
The VP-4 pager includes a plastic carrying case, lanyard, and battery.
- Four-Line or Two-Line Alphanumeric Display Format
- Message Time Stamp
- Unread Message Reminder
- Low Battery Indication
- Adjustable LCD Contrast
- Back-light Display
- In-Range Indication
- Date and Time Display
- Vibrate and Tone Modes
Weight | 1 lbs |
---|---|
Dimensions | 3 × 6 × 3 in |
Product Dimensions | 2.8" x 1.9" x 0.7" (W x H x D) |
Product Weight | 1.6 oz. |
Power | One 1.5 V AAA Battery |
Color | Semi-Transparent Black |
Operating Temperature | 14° – 130°F |
Humidity | 0% – 95%, Non-Condensing |
Alert Level | Minimum 75 db |
Display Format | Four Lines with Up to 22 Characters Per Line Two Lines with Up to 16 Characters Per Line |
Activation Codes | 6 |
Selectivity | Better than 65 db |
Spurious Rejection | Better than 60 PPM |
Image Rejection | Better than 50 db |
Stability | Better than 5 PPM |
Frequency | VHF (148 – 174 MHz), UHF (400 – 470 MHz) |
Paging Format | POCSAG, Narrow Band |
Data Baud Rate | 512, 1200 or 2400 BPS |
Receiver Sensitivity | 7u V/M |
Limited Warranty | One Year Parts and Labor |
